These images are compressed versions of high definition television (HDTV) images showing how Landsat data, which spans a very broad swatch of the electromagnetic spectrum, can be turned into images. The TIFF versions of these images are full resolution HDTV frames (1920 x 1080). All images have the HDTV standard aspect ratio (16:9).The Thematic Mapper (TM) on Landsat 4 and 5 observes reflected sunlight from the Earth all the way from blue in the visible part of the electromagnetic spectrum to shortwave infrared well beyond the ability of the human eye to percieve. The TM instrument also can observe infrared radiation actively emitted by the Earth from thermal infrared radiation. Landsat 7 carries an improved version of the TM instrument, called ETM+.

• Landsat Raw Data Sheet
• Landsat Raw Data Sheet

In addition to 7 channels of spectral data collected by the older TM instruments, ETM+ can observe in a special panchromatic band spanning the entire visible spectrum at twice the resolution of the TM bands (15 meter resolution instead of 30 meters). The ETM+ also has a major improvement in the resolution of the thermal band (60 meter resolution instead of 160 meters).A standard way to create images from raw Landsat TM and ETM+ data is to display a single band as a primary color, then combine different bands to create a full color image. Images shown here demonstrate combining three bands to make a color image using TM bands 5, 4, and 2, which covers a very broad range of the TM's spectral coverage.

Landsat Raw Data Sheet

Landsat Raw Data Sheet

It is also shown in combination with a digital elevation model. Terrain data is shown with vertical features exaggerated by a factor of three to emphasize details. Short URL to share this page:Used:1997/09/27Note: While we identify the data sets used in these visualizations, we do not store any further details nor the data sets themselves on our site.Keywords:DLESEDLESESVSDLESEGCMDNASA ScienceGCMD keywords can be found on the Internet with the following citation:Olsen, L.M., G. Scialdone, S.

Leicester, H. Grebas, C.Solomon, M. Northcutt, R. Bilodeau, 2013. NASA/Global Change Master Directory (GCMD) Earth Science Keywords. Version 8.0.0.0.0.
